Timken 2MM9305WI DUM Spindle & Precision Machine Tool Angular Contact Bearing -
Timken 2MM9305WI DUM Spindle & Precision Machine Tool Angular Contact Bearing -
Regular price
$449.99 USD
Regular price
Sale price
$449.99 USD
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Free Shipping to USA on orders under 50 lbs.
Couldn't load pickup availability
Timken 2MM9305WI DUM Spindle & Precision Machine Tool Angular Contact Bearing - 25 mm Bore, 42 mm OD, 9 mm Width, 15° Contact, Open. New old stock. From the stockroom of a closing industrial facility.
SPECIFICATIONS
| Bore Diameter | 25 mm |
|---|---|
| Outside Diameter | 42 mm |
| Overall Width | 9 mm |
| Closure Type | Open |
| Contact Angle | 15 ° |
| Ball Screw Application | Not for Ball Screws |
| Internal Clearance | C0 |
| Precision Rating | ABEC 7 (ISO Class 4) |
| Radial Dynamic Load Capacity | 1900 lbf |
| Radial Static Load Capacity | 1000 lbf |
| Maximum RPM | 34800 rpm |
| Cage Material | Phenolic Resin |
| Finish/Coating | Uncoated |
| Outer Ring Width | 9 mm |
| Fillet Radius | 0.3 mm |
| Series | 2MM9300WI |
| Standards Met | ABMA |
| Manufacturer UPC Number | 087796078017 |
| Type of Bearing | Spindle & Precision Machine Tool |
| Bore Diameter | 25 mm |
| Outside Diameter | 42 mm |
| Contact Angle | 15 ° |
| Closure Type | Open |
| Internal Clearance | C0 |
| Weight | 0.20 lbs |
